Client:Federal Police Command - Basra

Start DATE:2025-02-01

Location :Basra

The Scope of Work for Telecommunication Tower Construction includes site preparation by leveling the ground, followed by foundation work which involves excavation and pouring concrete to form a stable base for the tower. After the foundation is complete, the steel structure of the tower is assembled and erected, ensuring proper alignment and stability. Next, electrical wiring and cabling are installed to power the communication equipment. Finally, testing and commissioning are performed to ensure the tower is fully operational and meets safety and performance standards.

Client:HLV company

Start DATE:2023-01-11

Location :Hamar Mushrif

supply, erection, maintenance, and removal of formwork systems for the construction of reinforced concrete elements with Dim 10x8 m^2 No.10 and Lighting pole 9 m Foundation number 25 ,With Asphalt Road width 6 m and Length 800 m

Client:ZGC/ROO

Start DATE:2022-02-05

Location :South Rumaila Markazia DS

Installation of lighting pole QTY 35 and towers QTY 16, Ex flood light and Ex lighting junction box. Supply and installation of two control panel with photocell. Excavation, sand bedding, concrete cable tiles, cable laying, compacting, termination, and glanding. Fabricate, Supply, and installation of main DB to connect the new lighting system with the existing SWGR feeder. Walkdown, commissioning, signing GOC ITRs. MC1, SH1, and livening up certificate to be signed by all parties.

Client:ZGC/ROO

Start DATE:2022-08-30

Location :North Rumaila

Manual excavation for cable trench of 60 cm depth X 40 cm width QTY 200 m. Laying cables size 4x16mm^2 among Poles locations and Cable 4x50mm^2 from main supply DB panel and Lighting Control panels. Sand Bedding, Concrete cable laying, warning tape installation, and final compaction Compacting the trench according to the Supervisor requirements. Install Poles Foundations No.7. After complete all Leveling requirements. Supply and Install, lighting pole, heavy duty, base-hinged, 12m long, flange mounted, hot dip galvanized, tubular type. Install floodlight fixture, high pressure sodium (HPS) vapor 1x400w, 230v, 50hz with asymmetric wide beam reflector. Floodlight bracket, four flood lights mounting at any angles from 0 cent to 360 cents. On heavy duty lighting pole, Fix on top of pole overlap fit on Shaft. Termination, Connection and testing the above Cables from Two Side. Commission the Lighting System and sure from complete all works which related with Project. Maintenance Existed floodlight at External wall of workshop. Supply & Install Lighting Photo cell control panel IP66.

Client:ZGC/ROO

Start DATE:2019-03-15

Location :South Rumaila

Installation of lighting pole QTY 20 and towers QTY 2, Ex flood light and Ex lighting junction box. Supply and installation of two control panel with photocell. Excavation, sand bedding, concrete cable tiles, cable laying, compacting, termination, and glanding. Walkdown, commissioning, signing GOC ITRs. MC1, SH1, and livening up certificate to be signed by all parties.

Client:ZGC/ROO

Start DATE:2023-05-12

Location :North Rumaila / North Village

Pre fabrication E house concrete foundation along with excavation, transportation, and installation Preparing lifting plan, heavy equipment transportation plan, for shifting the new E house from RSB to NR Village site . Excavation of cable trench, sand bedding, laying concrete cable tiles, Laying new MV cable, compaction and connection at HT side. Installing RMU and connected the I/P and O/P MV cables with new termination and glanding. MC1, SH1, and livening up certificate to be signed by all parties

Client:ZGC/ROO

Start DATE:2022-11-22

Location :North Rumaila And South Rumaila

Supply material, equipment, and labor for Direct-buried Trench earth cables no.2 1x70mm2 from the LER room to the Air compressor Sunshade. Supply material, equipment and labor for Direct-buried Trench earth cables no.2 1x35 mm2 from Air compressor Sunshade Deasil tank structure Supply and Installing Concert cable Marker on the earth cable trench.

Client:ZGC/ROO

Start DATE:2022-08-30

Location :South Rumaila At Qurainat DS

Install cable tray Dim. 5 cm X 5 cm with length 36 m with cover. Install. U Polt with unit for cable tray support number 6. Install PVC pipe under concrete walkway with length 1 meter. Handle excavation Trench for laying cable With length. 15 meter. Install concrete tiles with dimension. 50 x 25 centimeter No.30 ea. And warning tape with length 15 meter. Backfilling the cable to arrange accordingly ROO requirements. Installing cable marker NO.4. Installing an instrument tubing pipe. From Flange to ESDV with length 5 m. Connected the tubing from two end with suitable fitting.

Client:FAJER UR /ROO

Start DATE:2024-01-05

Location :South Rumaila/BGC station

Prepare MS, RA, and certified staff from BGC Underground line detection Preparing lifting plan and PTW from ROO MKZ station HaydroVac excavation of cable trench with dimension 60x80 cm for length QTY 1000 m laying the cable inside depo ( underground room ) at BGC side to enter the cable at Switch gear Cable laying along the mentioned above route QTY 1000 m Sand bedding QTY 240 m3, concrete cable tiles QTY 2000, warning tape QTY 2000 m and compaction Supply and installation of joint cable 11 KV 3x185 QTY 1, End kit 11 KV 3 x185 mm QTY 2 Glanding, termination, and labelling Cable test, ITR

Client:ZGC/ROO

Start DATE:2023-11-06

Location :North RUMILA DS05

Designed Anode Test station and laying and connected Cable on pipes among wellhead(R231,R179,R277) and manifolds FM5/1A,FM5/1B Designed Anode Test station and laying and connected Cable on main pipe from FM5/1 TO DS05 Supply & Installing isolating flanged kids at every day

Client:FAJER UR/ROO

Start DATE:2023-10-20

Location :North Rumaila DS5

design and supply cathodic protection system ( anodes test point and cables). installing the anodes on the tow export pipe and submitted to the client . laying cable and install test poste No.2 . test and prepare ITRs and submitted to the client .

Client:ZGC/ROO

Start DATE:2022-12-04

Location :North Rumala DS5 / R021

Design, supply, installing and commissioning cathodic protection system on the underground section of pipe, and protection sleeve pipe at crossing road area.

Client:ZGC/ROO

Start DATE:2024-09-23

Location :North Rumaila /Wellhead R021,R575,R489,R498

Inspection cathodic protection system at road crossing Supply & Installation extra Zinc Anode For Underground Road Crossing. Supply and installation of new test stations

Client:ZGC/ROO

Start DATE:2023-04-04

Location :North Rumaila

Inspection cathodic protection system of well head pipe from wellhead (R210,R086,R177,R473,R238,R466) TO FM 5/B1 and FM 5/A1 manifold Supply and installation of new Zinc Anodes and reference electrode to enhance the system Supply and install flange insulation kit at the end side of flow lines with different sizes 8inch , 10inch. Supply and installation of new test stations

Client:ZGC/ROO

Start DATE:2022-10-25

Location :South Rumaila Mishrif Shamiya

installing LRC panel, step up transformer, Power unit, and emergency shutdown system at Mushrif Shamya Deggasing Station at main control room. Dismantle of existing transformers with structure. Excavation, laying cables, backfilling to replace the existing cable with new cable. Fabrication and installation cable trays with different sizes. Complete the commissioning works with GOC and ITRs.

Client:ZGC/ROO

Start DATE:2022-09-16

Location :South Rumaila M.Qurinat DS

Installation of lighting pole QTY 42 and towers QTY 10, Ex flood light and Ex lighting junction box. Supply and installation of two control panel with photocell. Excavation, sand bedding, concrete cable tiles, cable laying, compacting, termination, and glanding. Fabricate, Supply, and installation of main DB to connect the new lighting system with the existing SWGR feeder. Walkdown, commissioning, signing GOC ITRs. MC1, SH1, and livening up certificate to be signed by all parties.

Client:FAJER UR/ROO

Start DATE:2022-02-05

Location :South Rumaila Engineering Camp

Preparing the required MS, RA, and issuing Permit Perform underground line detection using GPR Excavation cable trench, sand bedding, laying MV cable, laying concrete tile, and compaction Insulation test, termination, glanding, and connecting DB Walkdown, commissioning, signing GOC ITRs. MC1, SH1, and livening up certificate to be signed by all parties.

Client:ZGC/ROO

Start DATE:2022-01-27

Location :North and South Rumaila Degassing Stations

Perform PM routine for UPS of type Borri E2001 , Liebert GXT4, and battery charger and if needed CM routine performed . Simulation shutdown procedure to check UPS response before livening up . Software upgrade if required . MC1, SH1, and livening up certificate to be signed by all parties.

Client:ZGC/ROO

Start DATE:2022-06-02

Location :South Rumaila

Prepare Lifting plan to shift the damaged transformer to our warehouse Perform the following tests Winding isolating test, Break down oil, and Winding ratio test . Main defects found 1- Leak of oil at HV primary 1U bushing. 2- Reduction of Mineral oil 3- Insulating mineral oil of transformer contain water content & contamination Final inspection before put online 1- Winding resistance measurement: By DLRO 10 Megger Brand . 2- Insulation resistance measurement: By MIT525 Megger Brand . 3- Transformer Turn ratio test: By TTR550503 3ph turn ratio Megger Brand .

Client:ZGC/ROO

Start DATE:2021-12-15

Location :North Rumaila

Manual Excavation cable trench depth 1m and width 40cm with length 750 m . Road Crossing Excavation and pipe sleeve installation Laying Cable 3x150 mm^2 with Length 760 m. Sand Bedding, Concrete cable laying, warning tape installation, and final compaction Cleaning the rusty electrical tower QTY 16 and painting them using galvanize paint after anti rust paint layer Repair the foundation of the existing Lighting towers No.16. Supply and installing Junction Boxes No.16 . Installing No.16 flood light. Laying Cable 4x16 mm^2 with Length 500 m among lighting poles. Laying earth cable 1x16mm^2 with length 500 m among the Lighting poles.

Client:ZGC/ROO

Start DATE:2022-01-18

Location :North Rumaila ESP well head

Discounted the Ends MV Cables from both sides (OHTL and RMU ) Excavation for purpose of extracting the Underground Cable runs to facilitate replacing the Faulty End cable.

Client:ZGC/ROO

Start DATE:2022-10-05

Location :South and North Rumaila

Replace the heavily damaged stay wires lean the rusty wire using chemical cleaner Supply and install the missing bolts Supply an install new galvanized shackle and to replace the missing Supply and install the missing clamps Uncover the buried foundation and paint the buried part of the tower with anti rust paint

Client:ZGC/ROO

Start DATE:2022-09-09

Location :North Rumaila

Supply and Installing 6.6KV OHTL A. Cable trench excavation from SWG to First Lattice tower. B. Sand Bedding, Concrete cable laying, warning tape installation, compaction, and End Cable Termination and Connection. C. Installing earth cable 1x120mm^2. At Area No.2 1- Supplying, installing, tubular poles, tension poles, crossing pole and H-pole. 2- Supplying, lay, test, overhead line wires ACSR-210/35 squ.mm. 3- Supplying, connect, and test ceramic insulators.

Client:ZGC/ROO

Start DATE:2021-09-16

Location :South Rumaila Qurainat and Shamiya

Prepare MS and RA for approval Check with operation team SORA in place override the Gas detector from system Perform function test for gas detectors The failure detector dismantles and sent to our workshop Perform calibration as per vendor through our certified team. Installation the calibrated and remove override for work.

Client:MAWARD AL TIQANIA

Start DATE:2023-07-30

Location :Welcome Square at Um Qasir Port

Design, Supply, and Installation of Distribution Panels in different sizes QTY 43 Mechanical cable trench excavation Cable Laying of different Size (4x10,25,35,50,70,95,150,185,240 mm2) QTY 20KM Sand Bedding, Concrete cable laying, warning tape installation, compaction, cable marker installation, and End Cable Termination and Connection.

Client:ZGC/ROO

Start DATE:2022-04-10

Location :North Rumaila

Supply and installing OHTL feeding from main existing 11 KV OHTL to police Camp. supply and install lighting poles with IP67 junction box and lighting control panel .

Client:ZGC/ROO

Start DATE:2022-02-22

Location :North Rumaila

Supplying, installing, tubular poles, tension poles, crossing pole and H-pole. Mechanical Excavation of pole foundation Supplying, installation, and testing of ACSR 120/20 Aluminum wire. Supplying, installation, and testing ceramic insulators Supplying, connecting, and testing of HV and LV Cables.

Client:ALMAJAL CO.

Start DATE:2022-01-22

Location :North Rumaila AL MAJAL CAMP

Supply and Install OHTL poles and ASCR wire Repair the damaged poles from Switchgear Room at old Rumaila to AL MAJAL camp. Remove the old Wires size 90 mm^2 and install wires with size 120/20 mm^2

Client:ZGC/ROO

Start DATE:2023-05-19

Location :North Rumila DS3 & DS4

Because the size of transformer Requirement changed the location of two transformer after disconnect cable from two MT/LT and Reconnect from two side Install RMU at DS3 Commissioning the two transformers after connected . Prepare Test and Inspection report. Prepare ITRs and GOC.

Client:FAJER UR/ROO

Start DATE:2023-08-05

Location :North Rumaila / Village

Loading transformer ,Unloading and installing transformer. Supply concrete foundation, Designed a concrete the size transformer. Laying MV cable after excavation trench depth 80 cm, width 40 cm and length 600 m. Make Joint cable to connect between tow Ends cable new and old . Termination End MV cable NO.2. Migger test Cable.

Client:ZGC/ROO

Start DATE:2021-09-06

Location :South Rumail Mishrif Shamiya

Issuing the necessary method statement, Risk Assessment, and SORA. Prepare bypass the gas detectors from the system. Dismantle the gas detector, calibrate them at our workshop after reinstalling. Perform function test and livening up them back.

Client:FAJER UR/ROO

Start DATE:2023-09-16

Location :North Rumaila DS04

heck /calibrate PWD PH1 level transmitters DS04(424-LIT-0001 & 424-LIT-0002)

Client:FAJER UR/ROO

Start DATE:2023-09-08

Location :North Rumaila DS04

Test and Configuration for Transmitter GWE LIT DS4 T2 LIT-2005

Client:FAJER UR/ROO

Start DATE:2023-03-27

Location :South Rumaila Qurainat

Disconnected ,calibrate and re-install and run of Transmitters Moisture Analyzer QURA564AI0001
